Camunda Optimistic Locking Exception — Root Cause & Fix
Camunda Optimistic Locking Exception — Root Cause & Fix
Introduction
If you work with Camunda BPM, sooner or later you will encounter an error called OptimisticLockingException.
Many developers panic when they see this exception in logs, assuming something is broken in the workflow engine. In reality, this exception is a normal concurrency protection mechanism used by Camunda to maintain consistent process data.
In this article we will cover:
What Camunda Optimistic Locking Exception is
The real root causes
Common scenarios where it occurs
Practical fixes and best practices
What is Optimistic Locking in Camunda?
Camunda uses optimistic locking to prevent multiple transactions from modifying the same database row at the same time.
When two transactions try to update the same record simultaneously, Camunda detects the conflict and throws an OptimisticLockingException instead of allowing inconsistent data to be saved.
This mechanism ensures that:
Process state remains consistent
Parallel execution does not corrupt workflow data
Failed transactions are rolled back safely
In simple words:
Two threads try to update the same process state → one succeeds → the other fails with OptimisticLockingException.
Root Cause of Optimistic Locking Exception
The main cause is concurrent modification of the same process entity.
Camunda stores process data in database tables such as:
ACT_RU_EXECUTIONACT_RU_TASKACT_RU_VARIABLE
Each record has a revision number (REV_).
Whenever an update happens:
Camunda reads row with version REV = 1
Two transactions try updating
First transaction updates → REV becomes 2
Second transaction still expects REV = 1
Camunda throws OptimisticLockingException
This is how the engine prevents lost updates.
Common Scenarios Where It Happens
1. Parallel Gateway Join
One of the most common cases.
When two parallel paths finish at the same time and reach the join gateway, both try to update the same execution entity.
Result:
ENGINE-03005 Execution update failed
OptimisticLockingException
This occurs because both executions attempt to update the same database row simultaneously.
2. Completing Same Task Twice
Example scenario:
User clicks Complete Task
Network delay occurs
User clicks Complete Task again
Two transactions try to complete the same task
One succeeds, the other throws OptimisticLockingException.
3. Parallel Service Tasks Updating Same Variable
Example:
Parallel Gateway
| |
Service A Service B
| |
Both update variable: status
Both threads attempt to update the same variable → conflict occurs.
4. Multi-Instance Tasks
Multi-instance loops maintain variables like:
nrOfCompletedInstances
nrOfActiveInstances
When multiple instances finish simultaneously, Camunda updates the same variable and may trigger optimistic locking.
How Camunda Handles It Automatically
When the Job Executor triggers the task, Camunda automatically retries the operation.
This means the failed transaction is rolled back and retried until it succeeds.
Therefore in many cases:
OptimisticLockingException is expected behaviour, not a bug.
Practical Fixes
1. Use Async Continuations
One of the most effective solutions.
Service Task
✔ Async Before
✔ Exclusive
This creates a transaction boundary, reducing conflicts.
2. Avoid Shared Variables
Instead of:
setVariable("status")
Use:
setVariableLocal("status")
Local variables reduce process-level conflicts.
3. Sequential Processing
If tasks modify the same data:
Avoid parallel execution.
Instead use:
Task A → Task B
4. Exclusive Jobs
Camunda provides exclusive job execution to prevent multiple jobs of the same process instance running simultaneously.
This significantly reduces optimistic locking conflicts.
5. Retry Strategy
If the exception happens in external tasks or APIs:
Implement retry logic:
retryCount = 3
retryInterval = 5s
Real-World Example
Consider an E-commerce order workflow:
Receive Order
|
Parallel Gateway
/ \
Check Stock Process Payment
\ /
Join Gateway
|
Confirm Order
If Check Stock and Process Payment finish simultaneously, the join gateway may produce OptimisticLockingException.
Adding Async Before on the join usually solves the issue.
Best Practices for Camunda Developers
✔ Avoid heavy parallel writes to the same process variables
✔ Use async continuations wisely
✔ Design workflows to minimize synchronization conflicts
✔ Implement retries for transient failures
✔ Monitor logs for frequent locking exceptions
Remember:
Occasional optimistic locking exceptions are normal in Camunda systems.
Recommended Resources
If you want to master Camunda and workflow architecture, I recommend learning these topics:
1️⃣ Camunda BPM Fundamentals
Understanding process engine architecture and transactions.
2️⃣ BPMN Workflow Design Patterns
Helps avoid concurrency issues.
3️⃣ Advanced Camunda Troubleshooting
Learn to debug incidents and job failures.
4️⃣ Workflow Scalability & Performance
Essential for enterprise systems.
Final Thoughts
The Camunda OptimisticLockingException is not an error in most cases — it is a safety mechanism to protect process data consistency.
Instead of trying to eliminate it completely, developers should:
Understand why it happens
Design better process models
Use async boundaries and retries
When handled correctly, Camunda workflows remain scalable, reliable, and consistent even under high concurrency.
