Camunda + Database Design (History Tables, Optimization, Scaling)
📌 Introduction
When working with Camunda, database design plays a critical role in performance, scalability, and maintainability.
Many production issues in Camunda projects are not due to BPMN design—but due to poor database planning.
👉 In this blog, we’ll cover:
- Camunda database architecture
- History tables & audit data
- Performance optimization
- Scaling strategies
🖼️ Camunda Database Architecture
Camunda uses a relational database with three main table categories:
📂 1. Runtime Tables (ACT_RU_*)
- Active process instances
- Running tasks
- Execution data
👉 Example:
ACT_RU_EXECUTIONACT_RU_TASK
📂 2. History Tables (ACT_HI_*)
- Completed processes
- Audit logs
- Task history
👉 Example:
ACT_HI_PROCINSTACT_HI_TASKINSTACT_HI_ACTINST
📂 3. General Tables (ACT_GE_*)
- Engine metadata
- Configuration
- Byte arrays
🔑 Why History Tables Matter
History tables are essential for:
- Audit & compliance
- Reporting
- Debugging production issues
👉 But they can grow very fast in production systems.
🖼️ History Data Flow
👉 Flow:
- Process executes
- Runtime data stored in
ACT_RU_* - On completion → moved to
ACT_HI_*
⚙️ History Levels in Camunda
Camunda provides configurable history levels:
| Level | Description |
|---|---|
| NONE | No history |
| ACTIVITY | Activity tracking |
| AUDIT | Default, basic audit |
| FULL | Complete details |
👉 Recommended:
- AUDIT → Production
- FULL → Debugging / critical systems
⚠️ Common Database Problems
❌ Huge history tables (millions of rows)
❌ Slow queries in Tasklist / Cockpit
❌ Deadlocks under high load
❌ Poor indexing
❌ Long-running transactions
⚡ Optimization Strategies
1️⃣ Indexing
Add indexes on:
PROC_INST_ID_EXECUTION_ID_TASK_ID_
👉 Improves query performance significantly
2️⃣ History Cleanup
Use built-in cleanup:
historyService.cleanUpHistoryAsync(true);
👉 Or configure TTL (Time To Live)
3️⃣ Partitioning
For large systems:
- Partition history tables by date
- Archive old data
4️⃣ Query Optimization
Avoid:
- Full table scans
- Unfiltered queries
Use:
- Pagination
- Indexed filters
🖼️ Optimization Flow
🚀 Scaling Strategies
🔹 Vertical Scaling
- Increase DB CPU/RAM
- Faster disks (SSD)
🔹 Horizontal Scaling
- Separate DB clusters
- Read replicas
- Microservices architecture
🔹 Camunda-Specific Scaling
- Async job executor tuning
- External task pattern
- Separate history database (advanced setups)
🔐 Best Practices
✅ Use proper history level
✅ Enable history cleanup
✅ Add DB indexes
✅ Monitor DB growth
✅ Archive old data
✅ Use connection pooling
✅ Tune job executor
🚀 Real-World Use Cases
- Banking audit systems
- Insurance workflows
- Government compliance tracking
- Enterprise BPM platforms
🔗 Reference Articles
🏁 Conclusion
A well-designed database is the backbone of any Camunda implementation.
👉 Focus on:
- History management
- Query optimization
- Scalability
This ensures your workflows run fast, stable, and production-ready.
